4MP WizColor Outdoor IP Camera 4MP WizColor

Name: DAHUA-4843
SKU: DH-IPC-HFW2449TLP-S-LED-0280B-PRO
Availability: InStock
Rating: 5 (44 reviews)

DAHUA-4843

DH-IPC-HFW2449TLP-S-LED-0280B-PRO

Main features

Dahua 4MP bullet IP camera with 2.8 mm Fixed lens
0.0005 lux
Warm illumination up to 50 m
H.265+ compression
WizColor technology
WDR 120 dB
Perimeter protection and SMD Plus
Built-in microphone
MicroSD slot
PoE or 12 VDC power supply
IP67 protection

Specifications

1/1.8" progressive scan CMOS sensor
Maximum resolution: 2688 × 1520 (4MP)
Fixed lens 2.8 mm
Angle of view: 112° (H), 60° (V), 134° (D)
Aperture: F1.0
Day/Night Mode: Color / B/W, with ICR Filter
Minimum illumination: 0.0005 lux (F1.0)
Warm illumination: up to 50 m
WDR 120 dB, BLC, HLC, 3D NR, ROI, Smart Illumination, LDC
Compression: H.265+, H.265, H.264+, H.264, MJPEG (substream)
Stream 1: 2688 × 1520 (1~20 fps), 2560 × 1440 (1~25/30 fps)
Stream 2: 704 × 576 (1~25 fps), 704 × 480 (1~30 fps)
Supported resolutions: 4MP, 3MP, 1080P, 1.3MP, 720P, D1, VGA, CIF
Built-in microphone
Audio: G.711a/u, PCM, G.726
Intelligent detection: line crossing, intrusion (classification of people and vehicles)
Smart features: SMD Plus, Smart Search (requires compatible NVR).
Events: motion, tampering, audio, SD failure, network disconnection, illegal access, IP conflict, voltage
Privacy masks: up to 4 zones
Storage: MicroSD slot up to 256 GB (card not included), FTP/SFTP, NAS
Network protocols: IPv4/IPv6, HTTP, TCP, UDP, RTP, RTSP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, NTP, UPnP, Multicast, ICMP, IGMP, NFS, PPPoE, P2P, Bonjour
ONVIF support: S, G, T / CGI profiles
Network interface: 1 × RJ45 10/100 Mbps
Clients: Smart PSS Lite, DSS, DMSS
Supported browsers: IE, Chrome, Firefox
Security: HTTPS, digest, WSSE, IP/MAC filtering, 802.1x, secure boot/run/update, X.509, syslog
Power supply: 12 VDC ±30 %, PoE (802.3af)
Basic power consumption: 2.0 W (12 VDC), 3.0 W (PoE)
Maximum power consumption: 5.6 W (12 VDC), 7.2 W (PoE)
Operating temperature: -40 °C to +60 °C (-40 °C to +60 °C)
Storage temperature: -40 °C to +60 °C (-40 °C to +60 °C)
Operating and storage humidity: ≤95% non-condensing
IP67 protection
Metal housing
Dimensions: 197.9 × 80.2 × 76.2 mm (197.9 × 80.2 × 76.2 mm)
Net weight: 0.57 kg
Gross weight: 0.72 kg

REFERENCE / MODEL	DAHUA-4843 / DH-IPC-HFW2449TLP-S-LED-0280B-PRO
Resolution	4MP
Audio	Microphone
IR Distance	41-80m
Ingress protection	IP67
Lens	2.8 mm
Special Protection	No
Sensor	1/1.8 CMOS
StarLight	StarLight
WDR (Backlight)	WDR (120dB)
Codec	H.264 \|\| H.264+ \|\| H.265 \|\| H.265+
PoE	PoE
SD Slot	Yes
Colour	White
Installation environment	Outdoor
Material	Metal
Alarm channels	No
Connectivity	IP \|\| YES (P2P)
AI Series	WizColor \|\| WizSense
Intelligent functions	Perimeter protection \|\| SMD Plus
Compatibility	Onvif

Documentation

	Language	Name	Type	Action
	EN		Manual
	EN		Self-generated File
