DAHUA-2242-FO | Dahua StarLight IP fixed dome with Smart IR of 30 m vandal resistant for outdoor
DAHUA-2242-FOIPC-HDBW2231F-AS-S2Dahua StarLight IP fixed dome with Smart IR of 30 m vandal resistant for outdoor

Dahua StarLight IP fixed dome with Smart IR of 30 m vandal resistant for outdoor

DAHUA-2242-FO

IPC-HDBW2231F-AS-S2

View newer model
Domo IP 2MP con iluminación dual DAHUA-4421

Main features

  • Dahua StarLight IP fixed dome with Smart IR of 30 m vandal resistant for outdoor
  • 1 / 2,8 ”CMOS of 2MP
  • Stream Dual
  • H.265 + / H.265 / H.264 + / H.264 / MJPEG format
  • Resolution up to 2MP at 25ips
  • ICR filter
  • 0.002 lux F1.6
  • 2.8 mm (106 °) fixed lens
  • OSD, AWB, AGC, BLC, HLC, WDR 120dB, 3D-DNR, 4 ROI zones, mirror, video sensor and privacy masks
  • Intelligent detection (IVS)
  • Two-way audio
  • It incorporates a microphone
  • 1 alarm input / 1 output
  • MicroSD slot
  • Onvif, CGI, P2P, Milestone
  • IP67, IK10
  • 3AXIS
  • 12V DC
  • PoE.

Specifications





Specs
    1 / 2,8 ”CMOS sensor, 2 megapixels
    Compression formats: H.265 + / H.265 / H.264 + / H.264 / MJPEG
    Digital Resolution: 1080P (1920 x 1080), 1.3MP (1280 x 960), 720P (1280 x 720), D1 (704 x 576), VGA (640 x 480), CIF (352 x 288)
    Dual stream
    Stream 1: 1080P (1 ~ 25 ips)
    Stream 2: D1 (1 ~ 25 ips)
    Day / night mode with removable mechanical filter
    Smart IR: 8 LEDs, 30 meters
    0.002 lux F1.6
    2.8mm fixed lens
    Viewing angle: 106 ° (H), 56 ° (V), 126 ° (D)
    White Balance: Auto, Natural, Street Light, Outdoor, Manual, Regional Settings
    Automatic and manual gain control
    Backlight compensation: BLC, HLC
    WDR 120dB
    3D-DNR digital noise reduction
    4 ROI zones
    4-zone rectangular video sensor
    4 zone privacy mask
    Mirror mode
    Intelligent detection (IVS): line crossing detection, intrusion detection
    1 RCA audio input / 1 output
    Incorporates microphone
    1 alarm input / 1 output
    MicroSD card slot up to 256GB (not included)
    Network interface: RJ45 (10/100 Base-T)
    Network protocols: IPv4, IPv6, HTTP, HTTPS, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, 802.1x, Bonjour
    Compatible with Onvif (profile S / G / T), CGI, P2P, Milestone, SDK, API
    Up to 20 users
    Remote viewing through IE, Chrome, Firefox browsers
    Smart PSS, DSS, DMSS management software
    Compatible with IOS and Android mobile devices
    Power: 12V DC
    Consumption: <5.4W
    Supports PoE
    Storage temperature -40 ° C ~ + 60 ° C
    -40 ° C ~ + 60 ° C operating temperature
    Relative humidity: ≤95%
    Degree of protection IP67
    IK10 vandal protection
    Metal housing
    Dimensions: Ø108.9 x 55 mm
    Weight: 380g
    3AXIS: -30 ° ~ 30 ° (PAN), 0 ° ~ 80 ° (TILT), 0 ° ~ 360 ° (Rotation)
    Does not include power supply



REFERENCE / MODEL DAHUA-2242-FO / IPC-HDBW2231F-AS-S2
Resolution 2MP
Audio 1 input / 1 output || Microphone
IR Distance 21-40m
Ingress protection IP67
Lens 2.8 mm
Special Protection Vandal-proof (IK10)
Sensor 1/3" CMOS
StarLight StarLight
WDR (Backlight) WDR (120dB)
Codec H.264 || H.265 || H.265+
PoE PoE
SD Slot Yes
Colour White
Installation environment Outdoor
Material Metal
Alarm channels 1 input / 1 output
Connectivity IP
Intelligent functions Perimeter protection
Compatibility Onvif
