Dahua 4MP mobile camera for passenger counting with M12 mounting

Name: DAHUA-4774
SKU: DH-IPC-HMW8441XP-M12-DAE-0200B-E
Price: 1088 EUR
Availability: InStock
Rating: 5 (75 reviews)

DAHUA-4774

DH-IPC-HMW8441XP-M12-DAE-0200B-E

Main features

IP camera for vehicles with passenger counting function
Resolution 4MP@30ips
Fixed lens of 2 mm with M12 mounting
Accuracy of 98%
0.002 lux and 14 m IR
Smart H.265+
Bidirectional audio and alarms
Metal housing
IP67 protection
Power supply 36 VDC/PoE

Specifications

1/2.8" CMOS sensor with 2560 × 1440 maximum resolution
Fixed lens 2 mm (F2.0) with M12 mount
Angle of view: 122° (H), 72° (V), 141° (D)
Day/night mode with ICR filter
0.002 lux (color) / 0.0002 lux (B/W) / 0 lux with IR
IR illumination up to 14 m
Video compression H.265, H.264 and MJPEG (substream)
Smart Codec: Smart H.265+ / Smart H.264+
Resolution: 4MP (2560 × 1440), 1080P (1920 × 1080), D1 (704 × 576 / 704 × 480)
Stream 1: 4MP (1~25/30 ips)
Stream 2: D1 (1~25/30 fps)
Stream 3: 1080P (1~25/30 fps)
Image functions: WDR 120 dB, BLC, HLC, 3D NR, ROI, rotation, adjustable white balance
Privacy: 4 configurable masks
Intelligent video functions:
- Passenger counting with Deep Learning algorithm.
- Counting accuracy greater than 98%.
Alarm events:
- Motion detection, tampering, network anomalies, digital input, video loss
Bi-directional audio: RCA input/output
Alarm: 2 inputs (5-24 V) and 2 outputs (12 V, 300 mA)
MicroSD slot up to 512 GB (card not included)
Network interface: RJ-45 10/100 Base-T
Network protocols: IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, SNMP, P2P
ONVIF (Profile S/G/T), CGI support
Software: Mobile Center
Mobile clients: Android / iOS
Power supply: 36 VDC or PoE 802.3af
Basic power consumption: 4 W
Operating temperature: -35 °C to +70 °C
Humidity: ≤95 %.
Storage temperature: -40 °C to +75 °C
IP67 protection
Vandal protection IK08
Metal housing
Dimensions (flush-mounted): 230 × 100 × 49.4 mm
Dimensions (bracket): 197.7 × 71 × 72.1 mm
Net weight: 0.76 kg (recessed) / 0.82 kg (bracket)
Gross weight: 0.91 kg (recessed) / 1.13 kg (stand).
Certifications: CE-LVD, CE-EMC, FCC, E-mark, EN50155, R118

REFERENCE / MODEL	DAHUA-4774 / DH-IPC-HMW8441XP-M12-DAE-0200B-E
Resolution	4MP
Audio	1 input / 1 output \|\| Two-way
IR Distance	10-20m
Ingress protection	IP67
Lens	2 mm
Special Protection	Vandal-proof (IK08)
Sensor	1/2.8" CMOS
StarLight	StarLight
WDR (Backlight)	WDR (120dB)
Codec	H.264 \|\| H.264+ \|\| H.265 \|\| H.265+
PoE	PoE
SD Slot	Yes
Colour	Grey
Installation environment	Indoor \|\| Outdoor
Material	Metal
Alarm channels	2 inputs / 2 outputs
Connectivity	IP \|\| YES (P2P)
Intelligent functions	People counting
Compatibility	Onvif
