DAHUA-3479 | Built-in 4K UHD USB camera
DAHUA-3479DH-VCS-C5A0Built-in 4K UHD USB camera
DAHUA-3479
DAHUA-3479_B
DAHUA-3479_C
DAHUA-3479_D
DAHUA-3479_E

Built-in 4K UHD USB camera

DAHUA-3479

DH-VCS-C5A0

This product is discontinued

Main features

  • Built-in Dahua 4K UHD USB camera
  • 8MP, H.264, MJPEG, YUY2, NV12
  • Optics with xoom 5X
  • BLC, 2D/3D-DNR
  • Mechanical PTZ + e-PTZ
  • Microphone and speaker. Bluetooth 5.0, HDMI, USB3.0, USB 2.0
  • 12V DC
  • Kensington lock

Specifications

8MP   Bluetooth

  • 8 megapixel 1/2.5" CMOS sensor
  • Digital resolution: 8MP (3840x2160), 1080P (1920x1080), 720P (1280x720), etc.
  • Compression format H.264, MJPEG, YUY2, NV12
  • 5X zoom optics
  • Angle of view: 110°(H), 75°(V), 121°(D)
  • Tripod head: mechanical PTZ + e-PTZ (±15 horizontal/tilt)
  • Picture modes: BLC, 2D/3D-DNR
  • Built-in microphone with 6-metre pick-up range
  • Built-in 96 dB SPL full-frequency speaker at 0.5 metres
  • USB Audio: 32K sample rate, UAC1.0 support
  • Communication interface: USB 3.0 (Type-C), USB 2.0 (Type-A)
  • Data communication via Bluetooth 5.0
  • UVC communication protocol 1.1 ~ 1.5
  • UVC PTZ control
  • HDMI 1.4b output
  • Power supply: 12V DC /2A
  • Storage temperature: -40°C ~ +60°C
  • Operating temperature: 0°C ~ +40°C
  • Security protection by Kensington Lock
  • Tabletop installation, wall mounting, with wall-mounted TV, etc.
  • Dimensions: 600 (W) x 135 (H) x 117 mm
  • Weight: 2.5 kg
