FOC-338
Central station of carbon monoxide detection of 4 zones
FOC-338
FOC-338
- MAIN FEATURES
- SPECIFICATIONS
- DOCUMENTATION
- COMMENTS
- Central station of carbon monoxide detection of 4 zones
- Two available systems, detection by semiconductor or electrochemical probe
- Up to 16 addressable and identifiable detectors per zone, individually during alarm or failure
- Central station of carbon monoxide detection of 4 zones
- Two available systems, detection by semiconductor or electrochemical probe
- Up to 16 addressable and identifiable detectors per zone, individually during alarm or failure
- 3 levels of programmable alarm
- 3 independent relay outputs
- Installation by 2 conductor wires on free architecture and without polarity
- Time of programmable ventilation start delay
- Time between detector readings 25 seconds
- Alarm indication on detector with red LED continuous illumination
- Normal operation indication of detectors by blinking every 25 sec
- Box of phosphated and painted steel plate
- Dimensions: 195 x 455 x 80 mm
- Certified system pursuant to UNE 23300-1984 standard by LOM
REFERENCE / MODEL | FOC-338 / FOC-338 |
---|---|
Zones | 4 |
