DAHUA-3227 | Managed Switch, 16 PoE + 2 Gigabit combo
DAHUA-3227DH-PFS4218-16ET-240-V3Managed Switch, 16 PoE + 2 Gigabit combo

Managed Switch, 16 PoE + 2 Gigabit combo

DAHUA-3227

DH-PFS4218-16ET-240-V3

This product is discontinued
It is replaced by the new version DAHUA-4243

Main features

  • Dahua Manageable Switch (L2) with 16 PoE 100Mbps ports + 2 Gigabit combo ports
  • CCTV mode (Cat5 up to 250m at 10Mbps)
  • PoE ports 1 and 2 support 90W
  • Web management with a friendly and easy-to-use interface
  • Watchdog PoE
  • Plug&Play.

Specifications

Specifications

Manageable Commercial Switch (L2) with 16 PoE ports + 2 combo (Gigabit RJ45 or SFP)
Ports 1 to 16: RJ45 PoE 10/100M
Ports 17 and 18 (combo, uplink): RJ45 (10/100/1000M) / SFP (1000M)
PoE consumption: ≤30W per port (ports 1 and 2 support 90W), ≤240W in total
PoE standards: IEEE802.3af, IEEE802.3at, Hi-PoE, IEEE802.3bt
Switching capacity: 8.8Gbps
Selectable CCTV mode (distance up to 250m with Cat5 and PoE working at 10Mbps)
Data and power transmission distance of 100m (at 100/1000Mbps) or 250m (at 10Mbps in CCTV mode)
Packet forwarding rate: 5.36 Mbps
MAC table: 4K
Power: 100V ~ 240V AC
Temp. operating: -10°C ~ +55°C
Relative humidity 10%~90%
Dimensions: 440 x 300 x 44mm

Documentation

Language Name Type Action
EN
Manufacturer's Data Sheet
