dahua
DAHUA-4247-V2 | Dahua Gigabit Gigabit Managed Cloud Switch with 8 PoE Ports
DAHUA-4247-V2DH-CS4010-8GT-110-V2Dahua Gigabit Gigabit Managed Cloud Switch with 8 PoE Ports
DAHUA-4247-V2
DAHUA-4247-V2_B
DAHUA-4247-V2_C

Dahua Gigabit Gigabit Managed Cloud Switch with 8 PoE Ports

DAHUA-4247-V2

DH-CS4010-8GT-110-V2

Main features

  • Dahua Managed Cloud Switch
  • 8 PoE ports and 2 Gigabit uplink
  • DoLynk Care management
  • 110W total PoE delivery with 90W BT port
  • Intelligent PoE and long distance PoE
  • STP/RSTP ring
  • Metal housing
  • ESD and surge protection
  • Desktop or wall mount installation

Specifications

Technical Features

  • Dahua Managed Cloud Switch
  • 8 x RJ-45 10/100/1000 Mbps PoE ports
  • 2 x RJ-45 10/100/1000 Mbps uplink ports
  • IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab compliant
  • 20 Gbps switching capacity
  • 14.88 Mpps forwarding rate
  • 15K Byte Jumbo Frame Size
  • 8K MAC table
  • 32 VLANS

Features

  • Cloud management via DoLynk Care (web and app)
  • Topology visualization via LLDP
  • PoE Watchdog with automatic reboot
  • Long distance PoE up to 250 m
  • STP/RSTP for loop protection
  • IEEE 802.3x flow control
  • DHCP client

Power supply

  • External power supply 54 VDC, 2.22 A
  • Standby power consumption ≤ 6 W
  • Maximum power consumption 110 W
  • Total PoE power ≤ 110 W
  • PoE port 1 up to 90 W; ports 2-8 up to 30 W

Environmental

  • Operating temperature -10 °C to +55 °C (-10 °C to +55 °C)
  • Operating humidity 5%-95% (non-condensing)
  • Storage temperature -40 °C to +70 °C (-40 °F to +70 °C)
  • ESD protection by air discharge 8 kV and contact 6 kV
  • Lightning protection in common mode 4 kV and differential mode 2 kV

Physical characteristics

  • Metal housing
  • Tabletop or wall mounting
  • Dimensions 190 × 106 × 30 mm
  • Net weight: 0.55 kg
  • Gross weight: 1.3 kg

Contents

  • DAHUA-4247-V2 10-Port PoE Managed Cloud Switch (DH-CS4010-8GT-110-V2)

Certifications

  • CE
REFERENCE / MODEL DAHUA-4247-V2 / DH-CS4010-8GT-110-V2
Range 250m
Technology Cloud || IP || POE || Watchdog
PoE 7 PoE+ || 8 PoE || 90W PoE || Hi-PoE || PoE || PoE+
CCTV Mode Yes
RJ45 Ports 10 (Gigabit)
Installation environment Indoor
Material Metal
Managed Browser || Cloud || DOLINK Cloud || L2
Ring RSTP || STP
PoE budget 101-150W
Installation Desktop || Rackable
Fan No
Uplink Ports 2 RJ45 Gb
Switch Type Access
Power Input Power Supply Included
