DAHUA-4440 | Dual thermal camera Dahua TPC5 Series
DAHUA-4440DHI-TPC-BF5641-B35Z3-DM-J-S2Dual thermal camera Dahua TPC5 Series
Volver a Thermal Cameras
Products
CCTV
Thermal Cameras
Bullet
DAHUA-4440
DAHUA-4440
DAHUA-4440_B
DAHUA-4440_C

Dual thermal camera Dahua TPC5 Series

DAHUA-4440

DHI-TPC-BF5641-B35Z3-DM-J-S2

Main features

  • Dahua TPC5 Series Hybrid Thermal Camera
  • Thermal sensor 640×512 with Fixed lens 35 mm
  • Visible sensor 4MP@25 ips with Motorized lens 10-30 mm
  • H.265 compression
  • ICR
  • 0.01 lux
  • IR illumination up to 80 m
  • WDR, BLC, HLC, DDE, 3D NR, ROI
  • Thermal detection, perimeter protection, person/vehicle classification
  • Two-way audio
  • MicroSD slot
  • IP67
  • PoE and ePoE

Specifications

  • Thermal sensor: vanadium oxide 640 × 512 px, 12 μm, NETD ≤ 35 mK
  • Visible sensor: 1/1.8" CMOS, 4MP (2688 × 1520)
  • Lens 35 mm fixed thermal (F1.0)
  • Thermal angle of view: 12.5° (H), 10° (V)
  • Lens motorized viewable 10-30 mm (F1.7)
  • Viewing angle visible: 42°-15° (H), 23°-8.4° (V)
  • ICR, Day/Night mode
  • Minimum illumination: 0.01 lux (color), 0.001 lux (B/W), 0 lux with white light
  • IR illumination up to 80 m
  • H.265 / H.264 compression
  • Thermal resolution: up to 1280 × 1024 @25/30 ips
  • Visible resolution: up to 2688 × 1520 @25/30 fps
  • WDR, BLC, HLC, DDE, Electronic Defog, ROI, 2D/3D NR
  • Digital zoom: up to 24x
  • Thermal detection: hot/cold spot, temperature detection
  • Intelligent functions:
    • Perimeter protection: line crossing, intrusion
    • People and vehicle classification
    • Heat detection
    • Smoke detection
    • Target tracking
  • MicroSD slot up to 512 GB (not included)
  • Bi-directional audio: 1 RCA audio input and 1 RCA audio output
  • 2 alarm inputs and 2 alarm outputs
  • Network interface: RJ-45 (10/100 Base-T)
  • RS-485
  • ONVIF, CGI, SDK compatible
  • Mobile clients: Android, iOS
  • Power supply: 12 VDC ±20 %, PoE (802.3af), ePoE
  • Max. power consumption: 15 W (12 VDC) / 18 W (PoE)
  • Operating temperature: -30 °C to +70 °C (-30 °F to +70 °C)
  • IP67 protection, overvoltage protection 6 kV
  • Metal housing
  • Dimensions: 130.2 (W) × 120.1 (H) × 321 mm (1.5 × 2.5 inches)
  • Net weight: ≤ 2.35 kg
  • Gross weight: ≤ 2.7 kg
  • Certifications: CE, FCC
REFERENCE / MODEL DAHUA-4440 / DHI-TPC-BF5641-B35Z3-DM-J-S2
Resolution 4MP
Audio 1 input / 1 output || Two-way
Ingress protection IP67
Lens 2~4X optical zoom
Special Protection No
Codec H.264 || H.265
PoE ePoE || PoE
SD Slot Yes
Thermal sensor FPA 12μm
Thermal lens 35 mm
Thermal resolution VGA (640x512)
Monitor Output BNC (960H)
Installation environment Outdoor
Alarm channels 2 inputs / 2 outputs
Intelligent functions Perimeter protection || SMD
