WITEK-0107 | 8 PoE+ Gigabit L2 manageable PoE switch 8 PoE+ + 2 SFP 2.5G
WITEK-0107WI-SP3010FM-L28 PoE+ Gigabit L2 manageable PoE switch 8 PoE+ + 2 SFP 2.5G
Volver a Switching
Products
Networking
Switching
Managed
WITEK-0107
WITEK-0107
WITEK-0107_B
WITEK-0107_C
WITEK-0107_D
WITEK-0107_E

8 PoE+ Gigabit L2 manageable PoE switch 8 PoE+ + 2 SFP 2.5G

WITEK-0107

WI-SP3010FM-L2

View newer model
Switch PoE gestionable L2 de 8 PoE+ Gigabit + 2 SFP 2,5G WITEK-0107N

Main features

  • Industrial-grade L2 Wi-Tek manageable PoE L2 switch
  • 8 Gigabit PoE+ ports
  • 2 SFP 2.5Gbps ports
  • 1 console port
  • 240W total PoE delivery
  • Extended temperature range of -40°C ~ +75°C.

Specifications

  • Wi-Tek industrial-grade Layer 2 Layer 2 manageable PoE switch
  • 8 PoE RJ45 100/1000Mbps ports
  • 2 uplink SFP 1000/2.5Gbps ports
  • 1 RJ45 console port
  • Standards and protocols:
    • IEEE 802.3: Ethernet
    • IEEE 802.3u: Fast Ethernet
    • IEEE 802.3ab: Gigabit Ethernet
    • IEEE 802.3x: Full Duplex Flow Control
    • IEEE 802.3az: Energy Efficient Ethernet
    • IEEE 802.3af: PoE
    • IEEE 802.3at: PoE+
  • PoE Consumption: ≤30W per port, 802.3af/at
  • Total PoE delivery of 240W
  • Forwarding type:Store-and-Forward forwarding
  • 26 Gbps switching capacity
  • 19.34 Mbps packet forwarding rate
  • MAC Addresses: 16K
  • Packet Buffer: 2 Mbit
  • Jumbo Frame: 10 kB
  • DC1 power supply (main): 44V ~ 57V DC
  • DC2 power supply (backup): 44V ~ 57V DC
  • Power consumption: 10W (standby), 250W (maximum, with PoE devices connected)
  • Storage temperature: -40°C ~ +85°C (-40°F ~ +85°F)
  • Storage relative humidity 5% ~ 95% (non-condensing)
  • Extended operating temperature -40°C ~ +75°C (-40°C ~ +75°C)
  • Operating relative humidity 10% ~ 90% (non-condensing)
  • DIN rail mounting compatible
  • Metal enclosure without fan
  • Dimensions: 179 (W) x 54 (H) x 124 mm
  • Net weight: 1180 g
  • Gross weight: 1340 g
  • Certifications: CE, FCC, RoHS, UKCA, RCM
REFERENCE / MODEL WITEK-0107 / WI-SP3010FM-L2
Special Protection Indoor (Temp Ext)
Technology FIBER || IP || POE
PoE 8 PoE || 8 PoE+ || PoE (M12) || PoE+
CCTV Mode No
RJ45 Ports 4 (Gigabit) || 8 (Gigabit)
Installation environment Indoor || Industrial
Material Metal
Managed Browser || Cloud || L2 || SNMP
Ring ERPS || RSTP || STP
PoE budget 201-250W
Installation DIN
Fan No
Uplink Ports 2 SFP 2.5 Gb || 2 SFP Gb
Switch Type Access || Industrial
Power Input 2 Power Input
