Unmanaged TP-Link 5-port 2.5 Gbps switch

TPLINK-267

TL-SG105-M2

Main features

Unmanaged TP-Link 5-port 2.5 Gbps switch
Switching capacity of 25 Gbps
Loop prevention
802.1p/DSCP QoS
IGMP Snooping support
Silent fanless operation
Compact metal housing with desktop or wall installation
External power supply included.

Specifications

Technical Features

TP-Link unmanaged switch
Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3bz, IEEE802.3x, IEEE802.1p
Ports: 5× RJ45 100 Mbps/1 Gbps/2.5 Gbps with Auto MDI/MDI-X
Switching capacity: 25 Gbps
Forwarding rate: 18.6 Mpps
MAC table: 4 K
Buffer memory: 8 Mbit
Jumbo frames: 12 KB

Features

Loop prevention
802.3X flow control
802.1p/DSCP QoS
IGMP Snooping
Transmission mode: Store and Forward

Power supply

External adapter included (9 V DC / 0.6 A)
Maximum power consumption: 5.64 W
Heat dissipation: 19.18 BTU/h

Physical characteristics

Metal housing
Installation: desktop or wall-mounted
Dimensions: 209 × 126 × 26 mm
Fanless operation

Environmental

Operating temperature: -5 °C ~ 40 °C
Operating humidity: 10 % ~ 90 % non-condensing

Contents

TPLINK-267 5-port 2.5 Gbps switch (TL-SG105-M2)
Power adapter
Installation guide
Rubber feet

Certifications

CE
FCC
RoHS

REFERENCE / MODEL	TPLINK-267 / TL-SG105-M2
Range	100m
Special Protection	No
Technology	IP \|\| UTP
PoE	No
CCTV Mode	No
Fiber type	No
Fiber Ports	No
RJ45 Ports	5 (2.5 Gigabit)
Installation environment	Indoor
Material	Metal
Managed	No
Ring	No
Installation	Desktop
Fan	No
Switch Type	Access
Power Input	Power Supply Included
Sub-brand	Omada by TP-Link

Documentation

	Language	Name	Type	Action
	DE		Self-generated File
