TPLINK-151

Panoramic IP 8MP camera with active deterrence and advanced analytics
TPLINK-151
InSight S385PI










Main features
Specifications
- 1/2.7" progressive CMOS sensor with a maximum resolution of 3840 × 2160
- Fixed lens 1.65 mm with F2.0 aperture and M12 mount
- Angle of view: 180° (H), 86° (V), 180° (D)
- Supported resolutions: 8MP (3840 × 2160), 4MP (2560 × 1440), 3MP (2304 × 1296), 2048 × 1280, 1080p (1920 × 1080), 720p (1280 × 720)
- Main stream: up to 30 fps at 8MP
- Secondary stream: up to 30 fps at 848x480,704x576, 640x480, 640x360,352x288, 320x240
- Video compression: H.265+, H.265, H.264+, H.264
- 0.005 lux (color), 0 lux with IR
- 4 IR LEDs with a range of up to 20 m (65 ft)
- Image functions: WDR, BLC, HLC, 3D DNR, ROI, privacy mask (up to 4 zones)
- Intelligent functions:
- Line crossing detection
- Intrusion detection
- Abandoned object detection
- Object removal detection
- Region entry detection
- Region exit detection
- Scene change detection
- Loitering detection
- Anomalous sound detection
- Person and vehicle classification
- Active deterrence with red-blue lights and audio
- Built-in microphone and speaker for two-way audio
- MicroSD card storage up to 512 GB (card not included)
- ONVIF compliant (Profile S, T, G)
- Network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, FTP/SFTP, RTP, IPv4, IPv6, ARP, SSL/TLS
- Supported software: VIGI App, VIGI VMS, Web UI, Cloud VMS
- RJ-45 10/100 Mbps network interface with PoE support (802.3af/at)
- Alarm interface: 1 input and 1 output
- Reset button included
- Power supply: 12 VDC ±5% or PoE; max. power consumption 12.14W
- Operating temperature: -30 °C to +60 °C (-30 °C to +60 °C)
- Storage temperature: -40°C to +60°C (-40°F to +60°F)
- Relative humidity: ≤95% non-condensing
- Metal housing
- IP67 protection
- IK10 protection
- Dimensions: 132 × 132 × 56 mm
- Net weight: 0.44 kg (without accessories)
- Gross weight: 0.48 kg (with accessories)
- 3AXIS: 0°~360°(PAN), 0°~90°(TILT), 0°~360°(Rotation)
- Certifications: CE, NTRA, KC, FCC, VCCI, BSMI, ONVIF.
REFERENCE / MODEL | TPLINK-151 / InSight S385PI |
---|---|
Resolution | 8MP |
Audio | Microphone || Speaker || Two-way |
IR Distance | 10-20m |
Ingress protection | IP67 |
Lens | 180° panoramic |
Special Protection | Vandal-proof (IK10) |
Sensor | 1/2.7" CMOS |
StarLight | StarLight |
WDR (Backlight) | WDR (120dB) |
Codec | H.264 || H.264+ || H.265 || H.265+ |
PoE | PoE || PoE+ |
SD Slot | Yes |
Colour | White |
Installation environment | Outdoor |
Material | Metal |
Alarm channels | 1 input / 1 output |
Connectivity | IP |
Intelligent functions | Abandoned objects || Perimeter protection |
Compatibility | Onvif |
Sub-brand | VIGI by TP-Link |
