Intelligent 24/48 V PoE converter

Name: WITEK-0137
SKU: WI-POE60-24V
Price: 25.571 EUR
Availability: InStock
Rating: 5 (38 reviews)

WITEK-0137

Wi-Tek intelligent PoE converter
2 RJ45 Gigabit ports with 1 48V PoE input (802.3af/at) and 1 24V passive PoE output
Plug&Play, no configuration required
Short circuit protection
Mini plastic housing

2 x 10/100/1000 Mbps RJ45 ports
1 PoE input port (802.3af/at)
1 PoE output port (24V 45+ 78-)
PoE power supply up to 24W
Power input: 48V ~ 55V DC or PoE input (802.3af/at)
Standby power consumption: 2W
Speed and link LED indicators
Transmission media:
- 10BASE-T: Category 3, 4, 5 UTP cable (max. 100 meters) EIA/TIA-568 100Ω STP cable (max. 100 meters)
- 100BASE-TX: Category 5, 5e UTP cable (max. 100 meters) EIA/TIA-568 100Ω STP (max. 100 meters)
- 1000BASE-T: UTP cable category 5, 5e, 6 (max. 100 meters)
Storage temperature from -40°C ~ +70°C
Storage humidity 5% ~ 90% (non-condensing)
Operating temperature -10°C ~ +55°C (-10°C ~ +55°C)
Operating humidity 10% ~ 90% (non-condensing)
Compact design without fan
Short-circuit protection
Plug&Play installation
Dimensions: 40,2 (W) x 25,1 (H) x 111 mm
Net weight: 65 g
Gross weight: 70 g
Certificates CE, FCC, RoHS, UKCA, RCM
