8MP IP dome with active deterrence and advanced analytics

Name: TPLINK-153
SKU: InSight S485(2.8mm)
Availability: InStock
Rating: 5 (54 reviews)

TPLINK-153

InSight S485(2.8mm)

Hoofd functies

Dome IP TP-Link VIGI 8MP@30ips
Fixed lens 2.8 mm
0.005 lux
WDR 120 dB, BLC, HLC, 3D DNR
Active deterrence with white light and audible warning
Detection of people and vehicles
Perimeter protection
Built-in microphone and speaker
MicroSD slot
IP67 protection
PoE

Specificaties

1/2.7" progressive CMOS sensor with 3840 × 2160 maximum resolution
Fixed lens 2.8 mm with F1.6 aperture and M12 mount
Angle of view: 111.4° (H), 58.8° (V), 134° (D)
Supported resolutions: 8MP (3840 × 2160), 4MP (2560 × 1440), 3MP (2304 × 1296), 2048 × 1280, 1080P (1920 × 1080), 720P (1280 × 720), WVGA (848 × 480), D1 (704 × 576), VGA (640 × 480), nHD (640 × 360), CIF (352 × 288), QVGA (320 × 240)
Stream 1: 8MP, 4MP, 3MP, 2048 × 1280, 1080P, 720P (1~25/30 ips)
Stream 2: WVGA, D1, VGA, nHD, CIF, QVGA (1~25/30 fps)
Video compression: H.265+, H.265, H.264+, H.264
Day/night mode with removable mechanical filter
0.005 lux (color), 0 lux with IR or white light
4 IR LEDs and 4 white light LEDs with range up to 30 m (100 ft)
Image functions: 120 dB WDR, BLC, HLC, 3D DNR, ROI, privacy mask (up to 4 zones)
Intelligent functions:
- Line crossing detection
- Intrusion detection
- Abandoned object detection
- Object removal detection
- Region entry detection
- Region exit detection
- Scene change detection
- Loitering detection
- Anomalous sound detection
- Person and vehicle classification
Active deterrence with flashing white light and audible warning
Built-in microphone and speaker for two-way audio
MicroSD card storage up to 512 GB (card not included)
ONVIF compatible (Profile S, T, G)
Network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, FTP/SFTP, RTP, IPv4, IPv6, ARP, SSL/TLS
Supported software: VIGI App, VIGI VMS, Web UI, Cloud VMS
RJ-45 10/100 Mbps network interface with PoE support (802.3af/at)
Reset button included
Power supply: 12 VDC ±5% or PoE; maximum power consumption 12.5W
Operating temperature: -30 °C to +60 °C (-30 °C to +60 °C)
Storage temperature: -40°C to +60°C (-40°F to +60°F)
Relative humidity: ≤95% non-condensing
Metal housing
IP67 protection
Dimensions: Ø111 × 83.7 mm
Net weight: 0.48 kg
3AXIS: 0°~360° (PAN), 0°~75° (TILT), 0°~360° (Rotation)
Certifications: CE, NTRA, KC, FCC, VCCI, BSMI, IC, ONVIF.

REFERENTIE / MODEL	TPLINK-153 / InSight S485(2.8mm)
Resolutie	8MP
Audio	Microfoon, Speaker, Two-way
IR afstand	21-40m
IP waarde	IP67
Lens	2.8 mm
Speciale bescherming	No
Sensor	1/2.7" CMOS
StarLight	StarLight
WDR (tegenlight)	WDR (120dB)
Codec	H.264, H.264+, H.265, H.265+
PoE	PoE, PoE+
SD Slot	Ja
Kleur	Wit
Installatieomgeving	Buiten
Materiaal	Metaal
Alarm kanalen	Geen
Connectiviteit	IP
Intelligente functies	Perimeter bescherming, Verlaten voorwerpen
Compatibiliteit	Onvif
Submerk	VIGI by TP-Link
